CU/LSNH-XL Stranded Copper Wire 630mm2, 450/750V, Green/Yellow, 1000m | Bahra Cables

Description

CU/LSNH-XL stranded copper wire by Bahra Cables, 630 mm2 cross-section, 450/750 volt rating, green/yellow color, and 1000 meter length. Features a nominal outer diameter of 36.2 mm, ideal for high safety electrical installations.

Product Description

Stranded copper wire CU/LSNH-XL, manufactured by Bahra Cables, is designed with a 630 mm2 conductor size and rated for 450/750 volts. Insulated using a low smoke halogen-free (LSHF) compound combined with cross-linked polymer (XL) technology, it offers enhanced resistance to heat, moisture, and UV exposure. This wire minimizes smoke and toxic fumes during fire incidents, making it ideal for safety-critical electrical installations in construction, industrial, and transportation sectors across Saudi Arabia.

Wire Type: H07 Z-R
Conductor: Annealed stranded copper
Cross-sectional Area: 630 mm2
Voltage Rating: 450/750 volt
Insulation: Low Smoke Halogen Free (LSHF) with Cross-linked polymer (XL)
Color: Green/Yellow
Length: 1000 meters
Nominal Outer Diameter: 36.2 mm
Standard: BS 7211
