Alfanar 10 mm2 Stranded Copper Wire 450/750V PVC Insulation 1mm Thick | Al Fanar

Name: Alfanar 10 mm2 Stranded Copper Wire 450/750V PVC Insulation 1mm Thick | Al Fanar
Brand: Al Fanar

Description

Alfanar 10 mm2 stranded copper wire with PVC insulation 1mm thick, rated for 450/750 volts, produced by Al Fanar. This electrical cable features a gray phase core and complies with BS and IEC standards, ideal for versatile electrical installations.

Product Description

Stranded copper electrical wire (CU/PVC) manufactured by Al Fanar under the trusted brand Alfanar Company, designed according to the latest BS and IEC standards. This wire features a durable 1mm thick polyvinyl chloride (PVC) insulation rated at 70 ºC, providing excellent protection against electrical leakage, mechanical shocks, abrasion, and UV damage. Its water and moisture resistance make it ideal for fixed internal installations, including wiring in control panels, machinery, instruments, lighting networks, and power systems.

Cross-sectional area: 10 mm2
Voltage rating: 450/750 V
Conductor type: Stranded copper (CU)
Insulation material: PVC (polyvinyl chloride)
Insulation thickness: 1 mm
Phase core color: Gray
Temperature rating: 70 ºC
Compliance: Latest BS and IEC standards
Applications: Fixed internal wiring, control boards, machines, instruments, lighting, power systems
