Alfanar 1.5 mm Single Wire 450/750V Stranded Copper Conductor PVC Insulation 0.7mm | Al Fanar

Name: Alfanar 1.5 mm Single Wire 450/750V Stranded Copper Conductor PVC Insulation 0.7mm | Al Fanar
Brand: Al Fanar

Description

Alfanar stranded copper wire 1.5 mm², 450/750V, with PVC insulation thickness of 0.7mm, manufactured by Al Fanar. This CU/PVC wire offers reliable performance, durability, and economical cost, featuring a gray phase core. Ideal for fixed internal electrical installations in Saudi Arabia.

Product Description

Stranded copper electrical wire (CU/PVC), manufactured by Al Fanar under the Alfanar brand, complies with the latest BS and IEC standards. This wire features a 1.5 mm² cross-sectional area and is insulated with 0.7 mm thick polyvinyl chloride (PVC) rated for 70 ºC, providing excellent insulation to prevent electric current leakage. It offers robust protection against shocks, abrasion, UV damage, water, and moisture, ensuring long-lasting performance. Designed for fixed internal installations, it is ideal for wiring control panels, machines, instruments, lighting networks, and power systems in the construction sector of Saudi Arabia.

Cross-sectional area: 1.5 mm²
Voltage rating: 450/750 V
Conductor type: Stranded copper (CU)
Insulation material: PVC (polyvinyl chloride)
Insulation thickness: 0.7 mm
Operating temperature: 70 ºC
Phase core color: Gray
Standards: Latest BS and IEC
Applications: Fixed internal installations, control boards, machines, lighting, power systems
