Galvanized Flange 75 mm Size, 8 mm Thickness | Union Pipe industry KSA

The galvanized flange by Union Pipe industry KSA is crafted from premium materials to deliver superior strength, durability, and resistance against rust and corrosion. Designed for easy installation and capable of withstanding high pressure, this flange is perfect for a wide range of construction applications including hot and cold water piping and sewage systems across Saudi Arabia.

• Size: 75 mm
• Flange Size: 65 mm (2 1/2 inch)
• Pitch Circle Diameter (P): 139.5 mm
• Inner Diameter (I): 92 mm
• Outer Diameter (D): 178 mm
• Thickness (T): 8 mm
• Number of Holes x Hole Diameter: 4 x 20 mm
• Material: Galvanized steel
• Brand: Union Pipe industry KSA
